1.0J spring impact hammer,led light test hammer,iec 60068-2-75 standard

Product Details:

Place of Origin:	China
Certification:	ISO 17025 calibration certificate
Model Number:	AT SIT10

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	negotiate
Packaging Details:	Standard tool case
Delivery Time:	stock
Payment Terms:	TT / credit card
Supply Ability:	1000 piece

Contact Now

Detailed Product Description

Product:	1.0J Spring Impact Hammer,led Light Test Hammer,iec 60068-2-75 Standard	Standard:	IEC 60068-2-75
Material:	Bearing Steel And Plastic	Certificate:	Calibration Certificate
AT SIT10:	0.14/0.2/0.35/0.5/0.7/1.0J Select One	AT SIT50:	0.14/0.2/0.35/0.5/0.7/1.0J Contain All

1.0J spring impact hammer,led light test hammer,iec 60068-2-75 standard

AT SIT10 0.14/0.2/0.35/0.5/0.7/1.0J select one energy

AT SIT12 2J spring hammer

AT SIT50 0.14/0.2/0.35/0.5/0.7/1.0J contain all

The spring impact hammer,from Allied Testing is designed and manufactured to perform the test specified in many standards to determine compliance with requirements concerning Mechanical Strength.

spring impact hammer, uses precision components for accurate results in laboratory or field use and can be used to test Electrical Appliances, Electrical Wiring Accessories, Luminaires, Connectors,etc. It is supplied with calibration report & comprehensive users manual. Several models are available.

Features:

*Precision manufacture according to the relevant standards.

* Single or universal energy is available

* Supplied in a compact carrying case.

* Precisely calibrated using IEC specified techniques.

Specification:

Impact energy: 0.14/0.2/0.35/0.5/0.7/1.0J (adjustable energy)

Weight of body: 1,25 Kg. ± 0,03 Kg.

Weight of striking element: 0,25 Kg. ± 0,01 Kg.

Weight of release cone: 0,06 Kg. ± 0,001 Kg.

Hammer head Hardness: 100 Rockwell

Hammer head material: Polyamide.
