The Adjustable spring hammer,universal spring impact hammer from Allied Testing is designed and manufactured to perform the test specified in many standards to determine compliance with requirements concerning Mechanical Strength.
Adjustable spring hammer,universal spring impact hammer uses precision components for accurate results in laboratory or field use and can be used to test Electrical Appliances, Electrical Wiring Accessories, Luminaires, Connectors,etc. It is supplied with calibration report & comprehensive users manual. Several models are available.
Features:
*Precision manufacture according to the relevant standards.
* Single or universal energy is available
* Supplied in a compact carrying case.
* Precisely calibrated using IEC specified techniques.
Specification:
Impact energy: 0.14/0.2/0.35/0.5/0.7/1.0J (adjustable energy)
Weight of body: 1,25 Kg. ± 0,03 Kg.
Weight of striking element: 0,25 Kg. ± 0,01 Kg.
Weight of release cone: 0,06 Kg. ± 0,001 Kg.
Hammer head Hardness: 100 Rockwell
Hammer head material: Polyamide.
· Hammer head radius: 10 mm.
· Dimensions:
o Diameter: 50mm ± 0,5mm.
o Body Length: 217mm ± 2mm.
Reference: IEC 60068-2-75
