IK10 20J 5kg impact test machine,pendulum impact test machine,IEC 60068-2-75

Product Details:

Certification:	ISO CE
Model Number:	IK10

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	negotiate
Packaging Details:	wooden case
Delivery Time:	stock
Payment Terms:	T/T
Supply Ability:	1000 piece

Contact Now

Detailed Product Description

Product:	IK10 20J 5kg Impact Test Machine,pendulum Impact Test Machine	Standard:	IEC 60068-2-75
Material:	Stainless Steel	Certificate:	Calibration Certificate
Appliance:	Electrical Product Shell Strength Test

IK10 20J 5kg impact test machine,pendulum impact test machine

IEC60068-2-75 Environmental testing – Part 2: Tests – Test Eh: Hammer tests, IEC60068-2-63, IEC62262 Degrees of protection provided by enclosures for electrical equipment against external mechanical impacts (IK code), IEC60439-5 Low-voltage switchgear and controlgear assemblies - Part 5:Particular requirements for assemblies for power distribution in public networks.

This device is suitable for mechanical impact strength test to electric cabinets and other sheet metal, shell of Non metal electric energy metering cabinet, substation cable switchboard and cable junction box.

Degrees of protection against external machanical impacts:

IKcode	IK01	IK02	IK03	IK04	IK05	IK06	IK07	IK08	IK09	IK10
Energy	0.14J	0.20J	0.35J	0.50J	0.70J	1.0J	2J	5J	10J	20J	50J
Equivalent mass 2%	0.25(0.2)	0.25(0.2)	0.25(0.2)	0.25(0.2)	0.25(0.2)	0.25(0.2)	0.5kg	1.7kg	5kg	5kg	10kg
